HOW TO GUIDE: Toyota Land Cruiser RKE Keyfob Programming

by

Toyota Land Cruiser RKE Keyfob Programming

The most efficient method for programming the RKE Keyfob on Toyota Land Cruisers from 1995 to 1996, 1997 to 1998, 1999 to 2000, 2001 to 2002, 2003 to 2004, 2005 to 2006, and 2007.

Toyota Land Cruiser 1995-1997  RKE Keyfob Programming

  1. Locate ECU Programming Receiver

    LOCATE the ECU Programming Receiver.rke

  2. Insert Key into Ignition

    INSERT key into Ignition and TURN to the ON position.

  3. Enter Programming Mode

    PRESS and HOLD the ECU’s Programming Switch for 3 seconds using a paperclip or small screwdriver. The Status Monitor LED light will turn on for 5 seconds to indicate successful entry into Programming Mode..

  4. Program Remote

    WITHIN 5 seconds, PRESS and RELEASE ANY button on the remote. The Status Monitor LED light will turn OFF, the piezo chirper will chirp ONCE and the exterior lights will flash ONCE to indicate successful programming of the remote. IF you hold the button too long and the vehicle alarm sounds, simply press the TOP button on the remote to reset the alarm.

  5. EXIT Programming Mode

    TURN OFF the Ignition to EXIT Programming Mode.

  6. Test Remotes

    TEST all remotes. Programming is complete.

Programming Notes:

  • Verify the following prior to following these instructions:
    • Your vehicle is equipped with keyless entry, and
    • You have a key fob remote that is compatible with your vehicle.
  • Obtain ALL remote transmitters for this vehicle.
  • Important: For MOST vehicles, the ECU Programming Receiver is located UNDERNEATH either the Driver or Passenger front seats. For SOME vehicles, it is located BEHIND the Driver’s Dash and can be accessed by prying out the black faceplate (5”x3”) BEHIND the mirror control switch. It is a BLACK box with 3 connectors and a recessed GREEN RESET button. Refer to the Owner’s Manual for your vehicle’s ECU location.

Toyota Land Cruiser 1998-2002  RKE Keyfob Programming

  1. Prepare Vehicle

    With the key OUT of the Ignition, OPEN and UNLOCK the Driver’s door.

  2. Enter Programming Mode – Step 1

    INSERT key into Ignition (Do NOT turn it) and REMOVE key.

  3. Enter Programming Mode – Step 2

    PERFORM the following steps WITHIN 40 seconds:

    a. Using the power lock switch on the driver’s door, perform 5 lock/unlock cycles starting with lock. Use an even pace and try to go about one cycle per second (1 Cycle = 1 lock and 1 unlock).

    b. CLOSE then OPEN Driver’s door.

  4. Enter Programming Mode – Step 3

    PERFORM the following steps WITHIN 40 seconds:

    a. Using the power lock switch on the driver’s door, perform 5 lock/unlock cycles starting with lock. Use an even pace and try to go about one cycle per second (1 Cycle = 1 lock and 1 unlock).

    b. INSERT key into Ignition.

    c. TURN ignition to ON (Do NOT Start) then back to OFF.
    – Do this ONCE to retain existing remotes programmed.
    – Do this TWICE to ERASE all existing remotes programmed and ADD NEW remote.
    – Do this THREE times to CHECK how many remotes are programmed to the vehicle.
    – Do this FIVE times to ERASE all existing remotes programmed.

    d. REMOVE key from Ignition.

  5. Enter Programming Mode – Step 4

    WITHIN 3 seconds the Power Door Locks should cycle LOCK/UNLOCK to signal successful entry into Programming Mode.

  6. Program Remote

    PERFORM the following steps WITHIN 40 seconds:

    a. PRESS the LOCK and UNLOCK buttons on the remote simultaneously for 1 second.

    b. PRESS and HOLD the LOCK button for 2 seconds. The Door Locks will cycle LOCK/UNLOCK to indicate successful programming of the remote.

  7. Program Additional Remotes

    REPEAT Steps 6a and 6b for any additional remotes to be programmed.

  8. EXIT Programming Mode

    CLOSE Driver’s Door to EXIT Programming Mode.

  9. Test Remotes

    TEST all remotes. Programming is complete.

Programming Notes:

  • Verify the following prior to following these instructions:
    • Your vehicle is equipped with keyless entry, and
    • You have a key fob remote that is compatible with your vehicle.
  • Obtain ALL remote transmitters for this vehicle.
  • If you have a remote head key with a transponder chip, this procedure will ONLY program the remote portion. You’ll need a Professional Auto Locksmith to cut and program the transponder key that will start the vehicle.
  • If you have a remote head key without a transponder chip, this procedure WILL work for your vehicle.
  • This procedure DOES NOT work for smart proximity remote key fobs.

Toyota Land Cruise 2003-2007  RKE Keyfob Programming

  1. Prepare Vehicle

    With the key OUT of the Ignition, OPEN and UNLOCK the Driver’s door.

  2. Enter Programming Mode – Step 1

    Perform the following steps within 5 seconds:

    a. INSERT key into Ignition (Do NOT turn) and PULL the key out.

    b. INSERT key into Ignition (Do NOT turn) and PULL the key out.

  3. Enter Programming Mode – Step 2

    PERFORM the following steps WITHIN 40 seconds:

    a. CLOSE then OPEN Driver’s door.

    b. CLOSE then OPEN Driver’s door.

    c. INSERT key into Ignition (Do NOT turn) and PULL the key out.

  4. Enter Programming Mode – Step 3

    PERFORM the following steps WITHIN 40 seconds:

    a. CLOSE then OPEN Driver’s door.

    b. CLOSE then OPEN Driver’s door.

    c. INSERT the key into the Ignition and LEAVE it in the Ignition.

    d. CLOSE the Driver’s door.

  5. Enter Programming Mode – Step 4

    TURN the Ignition to ON position (Do NOT crank engine) then back OFF.
    – Do this ONCE to retain existing remotes programmed and ADD NEW remote..
    – Do this TWICE to ERASE all existing remotes programmed and ADD NEW remote.
    – Do this THREE times to CHECK how many remotes are programmed to the vehicle.
    – Do this FIVE times to ERASE all existing remotes programmed.

  6. Enter Programming Mode – Step 6

    REMOVE key from Ignition. The power door locks will respond by cycling the locks from LOCK/UNLOCK to signal successful entry into Programming Mode.

  7. Program Remote

    Perform the following steps within 40 seconds:

    a. PRESS and HOLD the LOCK and UNLOCK buttons on the remote simultaneously for 2 seconds. RELEASE.

    b. PRESS and HOLD the LOCK button and hold for 2 seconds. RELEASE.

    The vehicle will respond by cycling the locks from LOCK to UNLOCK to indicate successful programming of the remote.

  8. Program Additional Remotes

    REPEAT Step 7 for any additional remotes to be programmed, including working ones.

  9. EXIT Programming Mode

    OPEN Driver’s Door to EXIT Programming Mode.

  10. Test Remotes

    TEST all remotes. Programming is complete.

Programming Notes:

  • Verify the following prior to following these instructions:
    • Your vehicle is equipped with keyless entry, and
    • You have a key fob remote that is compatible with your vehicle.
  • Obtain ALL remote transmitters for this vehicle.
  • If you have a remote head key with a transponder chip, this procedure will ONLY program the remote portion. You’ll need a Professional Auto Locksmith to cut and program the transponder key that will start the vehicle.
  • If you have a remote head key without a transponder chip, this procedure WILL work for your vehicle.
  • This procedure DOES NOT work for smart proximity remote key fobs.

Toyota Land Cruiser 2008-2022 RKE Keyfob Programming

You will need an OBD 2 scan tool that supports keyfob/RKE programming to effectively program the RKE key fob on a Toyota Land Cruiser from 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, or 2022. In this aspect, the Launch X431 Pro Series is simply one of many scanning tools available.



Toyota LandCruiser Prado Keyfob Programming

This is the programming instruction of the rke keyfob on the Toyota Land Cruiser Prado with the following Prado models: RZJ/GRJ/KZJ/KDJ/J120.

  1. Key Removed from Ignition
  2. Drivers Door open, all other doors closed
  3. Insert key into ignition then remove it – do this twice
  4. Close and open the drivers door twice
  5. Insert key into the ignition then remove it
  6. Close and open the drivers door twice
  7. Insert the key into the ignition, then close the door
  8. Turn the key from off to on – once to add a remote while retaining the original codes, or twice to rewrite the original remote codes (locks should cycle)
  9. Press the Lock and Unlock buttons on the remote at the same time for 1 second
  10. Press and hold any button on the remote for 2 seconds (locks should cycle once for correct programming, or twice if procedure is incomplete)
  11. To close programming, open the door of the vehicle.



Thank you very much! This tutorial was compiled and researched by Erwin Salarda.
