How to Adjust Camera Axis for Toyotas with OE Lift Kits
Are you ready to take your Toyota’s off-road game to the next level? Installing an OE lift kit is just the beginning! But wait—did you know that lifting your vehicle can throw off critical safety systems? Don’t let your adventure turn into a safety nightmare! Our ultimate guide reveals the step-by-step process to adjust the camera axis on your lifted Toyota, ensuring that all your Advanced Driver Assistance Systems (ADAS) function flawlessly.<>
Discover why recalibrating your camera is essential for features like Pre-Collision System and Lane Departure Alert, and learn about the must-have tools to get the job done right. From preparing your vehicle to troubleshooting common challenges, we cover it all!<>
Don’t risk your safety—click now to master the art of camera axis adjustment and keep your Toyota’s safety systems in peak condition. Your next off-road adventure awaits, and it starts with proper calibration!<>
Why Camera Axis Adjustment is Necessary After Installing a Lift Kit
When you install a lift kit on your Toyota, it changes the vehicle’s ride height and geometry. This alteration affects the positioning of the forward-facing camera mounted behind the windshield, which is a critical component of Toyota’s Safety Sense (TSS) system. The camera’s field of view is calibrated for the stock vehicle height, so lifting the vehicle throws off this calibration.<>
Some key ADAS features that rely on proper camera positioning include:<>
• Pre-Collision System (PCS)
• Lane Departure Alert (LDA)
• Dynamic Radar Cruise Control (DRCC)
• Automatic High Beams (AHB)<>
Without proper recalibration, these safety systems may not function correctly or could even malfunction, potentially compromising your vehicle’s safety.<>
Tools and Equipment Needed
Before beginning the camera axis adjustment process, you’ll need to gather the following tools and equipment:<>
• Toyota Techstream diagnostic tool
• Radar Adjusting Stand (SST 09870-60000)
• Reflector Target (SST 09870-60040)
• Printed calibration targets (available on Toyota’s Technical Information System)
• Measuring tape
• Plumb bob
• String
• Masking tape
• Marker
• Level surface for calibration<>
Step-by-Step Camera Axis Adjustment Process
1. Prepare the Vehicle
• Park the vehicle on a level surface
• Ensure tire pressures are set to factory specifications
• Clean the windshield thoroughly
• Connect the Techstream diagnostic tool to the vehicle’s OBD-II port<>
2. Access the Calibration Menu
• Turn on the ignition (do not start the engine)
• Using Techstream, navigate to the “Chassis” menu
• Select “Front Recognition Camera”
• Choose “Utility” and then “Transition to Online Axis Alignment Mode”<>
3. Set Up the Calibration Target
• Print the calibration targets from Toyota’s Technical Information System (TIS)
• Mount the targets on a sturdy cardboard backing
• Attach the targets to the Radar Reflector stand<>
4. Position the Target
• Use a plumb bob or laser level to determine the vehicle’s centerline
• Mark three positions in front of the vehicle:
– Center position: 3000mm (118 inches) from the front of the vehicle
– Left position: 750mm (29.5 inches) left of center
– Right position: 750mm (29.5 inches) right of center
• Place the Radar Adjusting Stand with the Reflector Target at the center position<>
5. Adjust Target Height
• Refer to the vehicle-specific information on TIS for the correct target height
• Adjust the Reflector Target height based on your vehicle’s grille type and lift kit height<>
6. Perform the Calibration
• Follow the on-screen prompts in Techstream
• Run the Front Beam Axis Adjustment
• Perform the Front Beam Axis Misalignment Reading
• Complete the Front Beam Axis Offset Reading
• Move the target to the left and right positions as prompted, repeating the process<>
7. Verify Calibration
• Check that all readings are within the specified range
• If any readings are out of range, double-check your measurements and target height<>
8. Clear Vehicle Control History (if required)
• For certain Toyota models with TSS, clear the Vehicle Control History after calibration
• This step is crucial for proper system operation<>
9. Road Test
• Take the vehicle for a test drive to confirm proper operation of all ADAS features
• Pay special attention to the Dynamic Radar Cruise Control and Lane Departure Alert systems<>
10. Final Scan
• Perform a post-calibration vehicle scan using Techstream
• Verify that no fault codes are present<>
Common Challenges and Troubleshooting
Even when following the procedure carefully, you may encounter some challenges during the camera axis adjustment process. Here are some common issues and how to address them:<>
Calibration Fails or Readings Out of Range
If the calibration fails or the readings are outside the specified range:<>
• Double-check all measurements and target positioning
• Ensure the vehicle is on a level surface
• Verify that the correct target height is being used for your specific vehicle and lift kit combination
• Check for any obstructions or damage to the camera or windshield<>
System Malfunctions After Calibration
If ADAS features are not functioning correctly after calibration:<>
• Clear the Vehicle Control History (if applicable for your model)
• Perform a complete system reset using Techstream
• Check for any loose connections or damaged wiring related to the camera or radar sensors<>
Inconsistent Performance
If the ADAS features work intermittently or seem unreliable:<>
• Ensure the windshield is clean and free of cracks or chips
• Check for any aftermarket accessories that may be interfering with the camera’s view
• Verify that all software updates have been applied to the vehicle’s systems<>
Best Practices for Camera Axis Adjustment
To ensure the best results when adjusting the camera axis on your lifted Toyota, keep these best practices in mind:<>
• Always refer to the latest Toyota Technical Service Bulletins (TSBs) and repair manuals for your specific model
• Use only OE-approved lift kits to maintain compatibility with Toyota’s calibration procedures
• Perform the calibration in a controlled environment with consistent lighting and a level surface
• Be patient and precise – rushing through the calibration process can lead to errors and safety issues
• Keep detailed records of the calibration process, including any measurements or adjustments made
• Consider having the calibration performed by an authorized Toyota dealership or ADAS specialist if you’re unsure about the process<>
The Importance of Regular Recalibration
It’s important to note that camera axis adjustment isn’t a one-time procedure. You should have your vehicle’s ADAS systems recalibrated:<>
• After any collision, even minor fender benders
• When replacing the windshield
• If you notice any issues with ADAS feature performance
• As recommended in your vehicle’s maintenance schedule<>
Regular recalibration ensures that your Toyota’s safety systems continue to function as intended, providing you with the maximum level of protection on the road.<>
The Future of ADAS Calibration for Lifted Vehicles
As vehicle technology continues to advance, we can expect to see improvements in ADAS calibration procedures for modified vehicles. Some potential developments include:<>
• Self-calibrating systems that can automatically adjust to changes in vehicle height
• More robust ADAS components that are less sensitive to minor alignment changes
• Advanced diagnostic tools that simplify the calibration process for DIY enthusiasts and professional technicians<>
However, for now, it’s crucial to follow the manufacturer’s recommended procedures to ensure your lifted Toyota’s safety systems are functioning correctly.<>
Conclusion
Adjusting the camera axis on your Toyota after installing an OE lift kit is a critical step in maintaining the functionality of your vehicle’s advanced safety systems. While the process can be complex, following the steps outlined in this guide and adhering to Toyota’s specifications will help ensure that your lifted vehicle continues to provide the same level of safety and driver assistance as it did in its stock configuration.<>
Remember, if you’re ever unsure about performing this calibration yourself, it’s always best to consult with a professional. Your safety and the safety of others on the road depend on these systems functioning correctly. By taking the time to properly adjust your camera axis, you’re not just maintaining your vehicle – you’re investing in your safety and the safety of everyone around you on the road.<>
FAQs
Q: How long does the camera axis adjustment process typically take?
A: The entire process, including setup and calibration, can take anywhere from 1 to 3 hours, depending on your experience level and the specific Toyota model.<>
Q: Can I drive my lifted Toyota before getting the camera axis adjusted?
A: While it’s possible to drive the vehicle, it’s not recommended. The ADAS systems may not function correctly, which could compromise your safety. It’s best to have the calibration done as soon as possible after installing the lift kit.<>
Q: Will adjusting the camera axis affect my vehicle’s warranty?
A: If you use an OE-approved lift kit and follow Toyota’s calibration procedures, it should not affect your warranty. However, it’s always best to check with your dealer for specific warranty implications.<>
Q: Can I adjust the camera axis myself, or do I need to take it to a dealership?
A: While it’s possible to perform the adjustment yourself if you have the necessary tools and expertise, many owners choose to have this done at a dealership or by an ADAS specialist to ensure accuracy.<>
Q: How much does a professional camera axis adjustment typically cost?
A: Costs can vary widely depending on your location and the specific Toyota model. Generally, you can expect to pay between $200 and $500 for a professional ADAS calibration.<>
By following this guide and keeping these FAQs in mind, you’ll be well-equipped to handle the camera axis adjustment process for your lifted Toyota, ensuring that your vehicle remains safe and compliant with all safety standards.<>
<>
